8X4 dump truck F2000

Name: 8X4 dump truck F2000
SKU: 0



LOCATION : HOME >> PRODUCTS >> Dump Truck >> 8X4 dump truck F2000

SHACMAN quality shapes the future

Overview

The F2000 series heavy duty trucks, with over 30 years of reputation, perfect for even the most difficult tasks, bring unprecedented values to its users.

Characteristic

Experienced Engineering

Lightweight world advanced design concept, inheriting the company's military qualities and over 41 years of manufacturing experience. Built to meet even the toughest demands and setting the bar for safety and efficiency. This series of vehicles utilizes Weichai engines, few leaf spring, lightweight high strength frame, rubber suspension and other advanced technologies. Utilizes WEVB engine exhaust breaking patented technology which increases breaking efficiency by more than 55%.

Superior Quality

Cabin utilizes high strength materials, left and right side doors are equipped with high strength anti collision beam, passed ECE-R29 crash test certification, lower floor to ensure the most driving room. Innovative use of lightweight high strength frame. Utilizes advanced Austria CRUISE software.

Product Parameters

Dump Truck
Drive type	6×4、8×4
Cabin	Lengthened high roof (N)Lengthened flat roof (J)Mid length flat roof (D)
Engine	Weichai power WP10, WP12
Emission Level	Euro II, III, IV, V
Transmission	Manual transmission 8F, 9F, 10FAutomatic transmission
Clutch	ETONФ430 diaphragm imported or Chinese manufactured
Front Axle	7.5 ton MAN drum type6.5 ton STR double front axle8 ton STR double front axle6.5 ton STR
Rear Axle	16 ton STR double stage casting (drum)16 ton MAN double stage casting (drum)
Suspension	Multi leaf spring configuration, 4 main piece + 2 U-bolts or 4 U-bolts
Frame（in mm）	850*300（8+7）
Fuel Tank	200 / 300 liter steel300 / 400 liter aluminum400 liter flat aluminum
Tires	11.00R20、12.00R20

Main specifications of SHACMAN F2000 6X4 Dump Truck
Model		SX3255DR384
Driving Type		6×4
Wheelbase (mm)		3775+1400
Curb weight (kg)		12370
Gross weight (kg)		25000
Overall Dimension (mm)	L	8495
	W	2500
	H	3450
Max. Speed (km/h)		78
Engine model		WEICHAI WP10.340E32
Rate power		340HP
Emission Standard		EURO II
Engine displacement(L)		9.726
Quantity of axle		3
Gearbox		US Eaton Fuller technology, FAST,9JS135T-B, 9 forward gears, 1 reverse gear, with synchronizer
Tire		12.00R20
Fuel tank capacity(L)		400L, Aluminum
Cab		German MAN technology, F2000 D Cabin, one sleeper, hydraulic seat for driver, electric window glass lifter, with A/C, hydraulic cabin suspension
Front axle		German MAN technology, HANDE, MAN 7.5T front axle
Rear axle		German MAN technology, HANDE, STR 16T rear axle, Hub Reduction, ratio 5.73
Fuel kind		DIESEL
Other Equipments		Manual cab tilting, Aluminum reservoir, 165Ah free-maintenance battery, desert air filter
Body		Dump box,5600x2300x1500 mm, bottom 10mm side 8mm, HYVA 137 front lifting hydraulic cylinder
QUALITY		26,000-30,000
FOB CHINA Port Price (USD)		100PCT BRAND NEW
